EAP912
AC1200 Wireless Gigabit Ceiling Mount Access Point
- Simultaneous 300Mbps on 2.4GHz and 867Mbps on 5GHz
- Adjustable power, reduce the interference between the AP
- Automatically weed out weak signal and improve wireless network performance
- Power adjustable to reduce interference
- Unified AP management without the need for additional AC controllers
- Support two power supply mode, more flexible networking
- Easy setup and support App management conveniently.
Specification
Hardware
|
Interface |
1 * 10/100/1000M adaptive LAN port(POE power supply) 1 * 10/100/1000M adaptive WAN port |
|
Antenna |
4 * built-in high gain antenna |
|
Button |
Default Button |
|
Power Supply |
48V standard POE or external DC 12V/1.5A power supply |
|
LED |
6 * red and blue LED |
|
Mounting |
Ceiling /Wall Mounting (Kits included) |
Software
|
Memory |
128MB |
|
FLASH |
16MB |
|
Forwarding rate |
10/100/1000Mbps |
Wireless
|
Frequency |
2.4 GHz and 5 GHz |
|
Signal Rate |
300Mbps at 2.4GHz, 867Mbps at 5GHz |
|
Wireless Standards |
IEEE802.11b/g/n/ac |
|
Features |
Wireless terminal Wireless network Intranet Settings Signal conditioning Host Black and white list Internet access Settings (routing mode/Bridge mode) Advanced Settings Port mapping Dynamic domain names(dyndns/noip/oray) Managing Passwords Time setting Initialization (Default restore) Schedule tasks (periodic restarts) Firmware upgrade (manual upgrade/online upgrade /AC upgrade) Dial-up log Device information Indicator light |
Others
|
Dimensions |
145 * 145 * 45mm |
|
Environment |
Operating Temperature : 0℃ ~ 40℃ Operating Humidity : 10% ~ 90% RH non condensing Storage Temperature : -20℃ ~ 70℃ Storage Humidity : 5% ~ 90% RH non condensing |
