Interface

8 10/100/1000M POE ports (Data /Power)

2 10/100/1000M RJ45 ports (Data)

LED

PWR: Lighting - The device is powered on normally

AI: Lighting - The intelligent mode is enabled

Port: Lighting - Port link is normal

Blinking - Data in transit

Mode

Normal Mode

Port VLAN + Watch Dog Mode

Store & Forwarding

Yes

Switching Capacity

20G

MAC Address Table Size

4K

Jumbo Frame

2048 byte

Power Input POE Standards

Single port maximum power 30W, whole switch maximum power 120W

Support over-current, over-voltage and short-circuit protection

Support Soft Start of High Power PD

Support sequential boot-up

Power Supply Pin:12+/36-

AC 100~240V 50-60HZ

Data Transfer Rate

10Mbps(Half-duplex and Full-duplex)

100Mbps(Half-duplex and Full-duplex)

1000Mbps(Full-duplex)

Basic function

Follow IEEE 802.3 Ethernet and IEEE802.3u Fast Ethernet Protocol

Support POE IEEE 802. 3af/at compliant Powered Device (PD)

Store-and-forward switching scheme

Support IEEE802.3X full duplex and Backpressure half duplex

MAC address auto-learning & auto-aging

VLAN port isolation

Watch Dog The AI automatically detects and restarts abnormal devices

Standards

IEEE 802.3 10BASE-T Ethernet

IEEE 802.3i 10BASE-T Ethernet

IEEE 802.3u 100BASE-TX Fast Ethernet

IEEE 802.3ab 1000BASE-T Gigabit Ethernet

IEEE 802.3af/at, Power over Ethernet

IEEE 802.3x Flow Control

Cabling type

1000Base-TX: Cat 5e or better UTP/STP(≤100m)

100Base-TX: Cat 5e or better UTP/STP(≤100m)

10Base-TX: Cat 5e or better UTP/STP(≤100m)

Environment

Operation Temperature：0℃～40℃

Storage Temperature：-40℃～70℃

Operation Humidity：10%～90% RH Non-condensing

Storage Humidity：5%～90% RH Non-condensing

Dimensions

190*140*43mm(L * W * H )
